SPECIFICATION OF REFINED SUGAR PLANT EQUIPMENTS:
| Sr. NO. | PARTICULARS | QTY. | |||||
| 1 | WATER STORAGE | TYPE | CAPACITY | HEAD | MOTOR HP | RPM | |
| DM WATER PUMP | 2 | CENTRIFUGAL | 1 M3/Hr | 40 | 0.7 | 1450 | |
| 2 | REFINERY PUMPS | TYPE | CAPACITY | HEAD | MOTOR HP | RPM | |
| PHOSPHORIC DOSING PUMP | 2 | 25 LPH | 3.5 | 0.25 | 1450 | ||
| CP DOSING PUMP | 2 | 25 LPH | 3.5 | 0.25 | 1450 | ||
| LIME DOSING PUMP | 2 | SCREW TYPE | 75 LPH | 3.5 | 0.25 | 1450 | |
| FLOCCULANT DOSING PUMP | 2 | 25 LPH | |||||
| RAW MELT PUMP | 2 | CENTRIFUGAL, SS-IMPELLER | 5 M3/Hг | 30 | 2.5 | 1450 | |
| SCREENED MELT PUMP | 2 | 5 M3/Hг | 30 | 2.5 | 1450 | ||
| FINE LIQUOR PUMP | 2 | 5 M3/Hг | 30 | 2.5 | 1450 | ||
| R2 MELT PUMP | 2 | 5 M3/Hг | 30 | 2.5 | 1450 | ||
| MOLASSES PUMP | |||||||
| R1HY MOLASSES PUMP | 2 | HI-FLOW | 5 M3/Hr | 25 | 2 | 1450 | |
| R1 LT MOLASSES PUMP | 2 | HI-FLOW | 5 M3/Hr | 25 | 2 | 1450 | |
| R1 LT MOLASSES PUMP | 2 | HI-FLOW | 5 M3/Hr | 25 | 2 | 1450 | |
| R2 MOLASSES PUMP | 2 | HI-FLOW | 5 M3/Hr | 25 | 2 | 1450 | |
| SUPER HEATER PUMP | 2 | C/F | 1 M3/Hr | 60 | 2 | 1450 | |
| SUPER HEATER PUMP | 2 | C/F | 1 M3/Hr | 60 | 2 | 1450 | |
| MAGMA PUMP | CAPACITY | HEAD | RG TYPE | RATIO | |||
| SUGAR MAGMA PUMP | 2 | 5 M3/Hr | 20 | 40,1 | |||
| R2 SUGAR MAGMA PUMP | 1 | 5 M3/Hr | 20 | 40,1 | |||
| 3 | SUPPLY TANK | DIA | HEIGHT | VOLUME | |||
| DM WATER STORAGE TANK | 1 | 1500 | 2800 | 4.95 | VERTICAL CYLINDRICAL | ||
| SCREENED MELT BUFFER TANK | 1 | 1500 | 2800 | 4.95 | VERTICAL CYLINDRICAL | ||
| CLEAR MELT TANK | 1 | 1500 | 2800 | 4.95 | VERTICAL CYLINDRICAL | ||
| LIQUOR SUPPLY MELT TANK | 1 | 1500 | 2800 | 4.95 | VERTICAL CYLINDRICAL | ||
| BACK WASH TANK | 1 | 1500 | 2800 | 4.95 | VERTICAL CYLINDRICAL | ||
| 4 | STORAGE TANK | DIA | HEIGHT | VOLUME | |||
| LIQUOR TANK | 2 | 2390 | 1810 | 8.12 | |||
| MELT STORAGE TANK | 1 | 2390 | 1810 | 8.12 | |||
| R1HY MOLASSES TANK | 1 | 1500 | 1810 | 8.2 | |||
| R1LT MOLASSES TANK | 1 | 2390 | 1810 | 8.12 | |||
| R2 MOLASSES TANK | 1 | 1500 | 1810 | 8.2 | |||
| 5 | PAN | CAPACITY | S/V RATIO | TUBE SIZE | MOC | VAPOUR INLET/OUTLET | |
| PAN NO 1 | 1 | 7T | 8 | 98 ID/1200 LONG | SS-409 | 300/500 | |
| PAN NO 2 | 1 | 7T | 8 | 98 ID/1200 LONG | MS-2062 | 300/500 | |
| Mechanical Circulator | 2 | ||||||
| 6 | REFINERY | DIA | HEIGHT | Volume(M3) | RG RATIO | ||
| MELT CLARIFIER | 1 | 2390 | 1800 | RPM 2-4 | 8.07 | 45:7 | |
| MELT REACTION VESSEL | 1 | 700 | 1000 | 0.38 | 45:7 | ||
| PHOS ACID TANK | 2 | 300 | 700 | 200 It | 0.05 | ||
| CP TANK | 2 | 300 | 700 | 500 It | 0.05 | ||
| MOL TANK | 1 | 300 | 700 | 500 It | 0.05 | ||
| MOL PREP TANK(RPM 8) | 1 | 300 | 700 | 500 It | 0.05 | 29,45 | |
| FLOCCULENT TANK | 1 | 300 | 700 | 500 It | 0.05 | ||
| MULTI-BED FILTER | 1 | 1500 | 2800 | 5 M3 | |||
| VIBRO SCREEN | 2 | 48" DIA | 60 MESH | ||||
| HEATER (DCH/TUBALAR) | 1 | ||||||
| CRYSTALLIZER | DIA | LENGTH | RG TYPE | RG | |||
| REFINED VACUUM CRYT | 1100 | 3400 | 1259;1 | ||||
| REFINERY SEED CRYT | 1100 | 3400 | 1259;1 | ||||
| MOC | |||||||
| MOC REFINED M/C CRYT NO1 | 1500 | 4200 | SS-409 | 1415;1 | |||
| REFINED M/C CRYT NO2 | 1500 | 4200 | MS-2062 | 1415;1 | |||
| 8 | PUG MILL & MAGMA MIXER | DIA | LENGTH | RG TYPE | RG | ||
| REFINED PUG MILL | 1 | 1100 | 2000 | RPM 2.5-3.0 | 40:1 | ||
| R2 PUG MILL | 1 | 1100 | 2000 | RPM 2.5-3.0 | 40:1 | ||
| 9 | MAGMA MIXER | DIA | LENGTH | RG TYPE | RG | ||
| MINGLER | 1 | 1400 | 1500 | RPM-24 | U-600 | 20:1 | |
| R2 MINGLER | 1 | 900 | 1100 | RPM-24 | U-600 | 20:1 | |
| 10 | MELTER | DIA | LENGTH | RG TYPE | RG RATIO | ||
| R2 MELTER | 1 | 2390 | 1800 | 77:2 | |||
| SUGAR MELTER | 1 | 2390 | 1800 | 77:2 | |||
| DE-SWETENER CLARIFIER | 1 | 1500 | 1810 | RPM-24 | 45:7 | ||
| 11 | CENTRIFUGAL | CAPACITY | MOTOR KW | ||||
| REFINERY C/F NO 1 | 1 | 200 TO 650 Kg/Charge | SUITABLE | 60 ΤΟ 110 | |||
| 12 | SUGAR HOUSE | ||||||
| MOTOR HP | RPM | RG RATIO | TEETH OF RG | TEETH OF SHAFT | |||
| ELEVATOR | 1 | 3.5 | 1440 | 40:1 | 13 | 25 | |
| GRADER | 1 | 5 ΤΡΗ | 985 | 25 | 2200 | 985 | |
| SUGAR BIN | 1 | 2000 | 1200 | 1700 | |||
| 13 | ELECTRICALS | ||||||
| 14 | AUTOMATION & INSTRUMENTATION | ||||||
| 15 | VALVES, PIPING | ||||||
| 16 | CIVIL WORK | ||||||
| 17 | STAGING & STRUCTURE |
